High-Speed Printing:

Capable of printing up to 200 mm/sec, ensuring fast customer service and reduced queue times.

Thermal Printing Technology:

Eliminates the need for ink or ribbon, reducing maintenance and operating costs.

Compact & Durable Design:

Sturdy build quality with a small footprint, perfect for space-constrained environments.

User-Friendly Operation:

Easy paper loading with a drop-in mechanism and simple LED indicators for power and error status.

Interface Options:

Comes with USB + Serial + Ethernet (LAN) interfaces, ensuring seamless connectivity with POS systems, PCs, and networks.

Print Resolution:

203 dpi resolution for sharp and clear text and graphics on receipts.

Paper Width Support:

Supports standard 80 mm (3-inch) wide thermal paper rolls.

Auto Cutter:

Built-in high-quality auto-cutter for clean and quick receipt cutting.

Compatibility:

Supports Windows/Linux OS, ESC/POS command compatibility for easy integration with most billing software.

Power On:

Connect the power cable and switch ON the printer.

Load Paper:

Open the paper cover.

Place the thermal paper roll with the printing side facing up.

Pull a small portion of paper out and close the cover.

Connect to System:

Use the USB or serial cable to connect to your POS system or computer.

Install the correct driver if required (available from TVS website).

Print Test Page:

Hold the Feed button and power ON the printer to print a self-test page.

Printing:

Send the print command from your POS/billing software.

Use the Feed button to advance the paper manually.

Replace Paper:

When the paper is low, the printer will flash a red light.

Replace the roll as described above.

Error Indicators:

Red Light Flashing: Paper out or paper jam.

No Light: Check power connection.
